Steelveron

Alloy 20 Forged Fittings

Steelvron is a leading Alloy 20 Forged Fittings Supplier, Manufacturer, and Exporter, offering high-performance forged fittings engineered for outstanding corrosion resistance and mechanical strength. Alloy 20 is specifically designed for chemical, pharmaceutical, and refining industries, where acidic conditions, high pressure, and elevated temperatures demand reliable and durable piping solutions.

Overview

Our Alloy 20 Forged Fittings are manufactured from premium Alloy 20 materials, ensuring superior resistance to sulfuric acid, hydrochloric acid, and other corrosive chemicals, while maintaining excellent mechanical stability and longevity. These fittings are ideal for high-pressure and high-temperature pipelines, reducing maintenance needs and ensuring consistent operational performance.

Steelvron employs advanced forging processes and rigorous quality checks to produce fittings with precise dimensions, uniform wall thickness, and leak-proof connections. All products meet ASTM, ASME, DIN, EN, and JIS standards, delivering reliability, safety, and efficiency for complex chemical and industrial piping systems.

We offer a comprehensive range of Alloy 20 Forged Fittings, including elbows, tees, reducers, caps, crosses, couplings, and custom-designed components, tailored to meet project-specific requirements and challenging industrial environments. Choosing Steelvron ensures durable, corrosion-resistant solutions for critical chemical, pharmaceutical, and refining pipelines.

Technical Specifications of Alloy 20 Forged Fittings

Standards:

ASTM B462 / ASME SB462, MSS-SP-79, MSS-SP-83, ANSI, DIN, EN, JIS

Grades Available:

Alloy 20

Forms:

Elbows, Tees, Crosses, Reducers, Couplings, Unions, Plugs, Bushings, Custom Forged Fittings

Size Range:

½” (15 NB) to 6” (150 NB)

Pressure Class:

150, 300, 600, 900 LBS

Finish:

Polished, CNC Machined, Pickled & Passivated

Chemical Properties Of Alloy 20 Forged Fittings

Grade	Ni (min)	Cr (min)	Fe (balance)	Mo (min)	Cu (max)	C (max)	Mn (max)	Si (max)
Alloy 20	32	19	Balance	2.5	1	0.06	2	1

Physical Properties of Alloy 20 Forged Fittings

Property

Alloy 20

Density (g/cm³)

8.0

Tensile Strength (MPa)

550–750

Yield Strength (MPa)

275

Elongation (%)

35–45

Hardness (HB)

180–220

Operating Temp

Up to 450°C

Types Of Alloy 20 Forged Fittings We Offer

Alloy 20 Pipe Cap Fitting

Alloy 20 Pipe Cross Fitting

Alloy 20 Pipe Bend Fitting

Alloy 20 Short Stub End Fitting

Alloy 20 Long Stub End Fitting

Alloy 20 Concentric Reducer Fitting

Alloy 20 Eccentric Reducer Fitting

Alloy 20 Tee Fitting

Alloy 20 Elbow Fitting

Materials We Offer

Carbon Steel Forged Fittings

Duplex or Super Duplex Forged Fittings

Duplex Steel 31803/32205

Super Duplex S32760/S32750

Titanium Forged Fittings

Stainless Steel Forged Fittings

FAQ

Your complete guide to understanding Steelvron’s products, materials, certifications, and industrial applications worldwide

Why choose Steelvron as your Alloy 20 Forged Fittings Supplier?

Steelvron provides high-quality Alloy 20 forged fittings with excellent acid resistance and compliance to ASTM, ASME, DIN, EN, and JIS standards, ensuring reliable performance in chemical, pharmaceutical, and refining industries.

Which grades of Alloy 20 Forged Fittings do you supply?

We supply Alloy 20.

What is the size and pressure class range available?

Sizes range from ½” (15 NB) to 6” (150 NB) with pressure ratings of 150, 300, 600, and 900 LBS.

Are Alloy 20 Forged Fittings suitable for acidic and corrosive environments?

Yes, Alloy 20 provides superior resistance to sulfuric acid, hydrochloric acid, and other corrosive chemicals, making it ideal for chemical and pharmaceutical pipelines.

Can Steelvron provide customized Alloy 20 forged fittings?

Yes, we manufacture tailor-made fittings as per client specifications and project requirements for precise fit and optimal performance.

Why Choose Us?

Global Expertise

Trusted manufacturer, supplier, and exporter of Alloy 20 Forged Fittings worldwide.

Complete Range

Comprehensive portfolio covering all Alloy 20 Forged Fittings materials and types, ensuring broad compatibility.

Certified Quality

ISO-certified facilities ensure strict manufacturing and testing, delivering precision products consistently.

International Standards

Products meet ASME, ANSI, DIN, EN, BS, and JIS norms, ensuring acceptance.

Custom Solutions

Supplying standard and tailor-made Alloy 20 Forged Fittings, crafted to match exact specifications.

Worldwide Reach

Exporting to 50+ countries with a proven record of client satisfaction.

Property	Alloy 20
Density (g/cm³)	8.0
Tensile Strength (MPa)	550–750
Yield Strength (MPa)	275
Elongation (%)	35–45
Hardness (HB)	180–220
Operating Temp	Up to 450°C
