Stainless Steel Forged Fittings

Stainless Steel Forged Fittings

Steelvron is a leading Stainless Steel Forged Fittings Supplier, Manufacturer, and Exporter, delivering precision-engineered forged fittings that provide exceptional strength, corrosion resistance, and durability. Designed to perform under high pressure and extreme temperature conditions, our stainless steel forged fittings are widely used across industries such as oil & gas, petrochemicals, power generation, pharmaceuticals, food processing, and marine engineering.

Overview Technical Specifications Properties Types Materials FAQ

Overview

Our forged fittings are manufactured from premium-quality raw materials and undergo stringent quality checks to ensure leak-proof connections, dimensional accuracy, and long service life. As a trusted Stainless Steel Forged Fittings Supplier, Steelvron provides fittings in multiple grades such as SS 304/304L/304H, SS 309/310/310S, SS 316/316L/316Ti, SS 317/317L, SS 321/321H, SS 347/347H, and SS 904L, making them suitable for a wide range of industrial applications.

Produced according to international standards like ASTM, ASME, DIN, EN, and JIS, our stainless steel forged fittings are available in various types including Elbows, Tees, Crosses, Couplings, Unions, Nipples, Bushings, and Plugs. With CNC machining, polished finishes, and precise threading, Steelvron ensures unmatched performance and reliability for both standard and customized solutions.



Technical Specifications of Stainless Steel Forged Fittings

Standards:

ASTM A182 / ASME SA182, ANSI, DIN, EN, JIS, BS

Grades Available:

SS 304/304L/304H, SS 309/310/310S, SS 316/316L/316Ti, SS 317/317L, SS 321/321H, SS 347/347H, SS 904L

Size Range:

½” (15 NB) to 4” (100 NB)

Pressure Ratings:

Class 2000, 3000, 6000, 9000

Connection Types:

Socket Weld, Threaded (NPT/BSP)

Finish:

CNC Machined, Smooth, Polished

Chemical Properties Of Stainless Steel Forged Fittings

Grade

C (max)

Mn (max)

Si (max)

P (max)

S (max)

Cr

Ni

Mo

N (max)

SS 304/304L

0.08/0.03

2.0

0.75

0.045

0.03

18–20

8–12

–

0.10

SS 310/310S

0.25/0.08

2.0

1.5

0.045

0.03

24–26

19–22

–

0.10

SS 316/316L

0.08/0.03

2.0

0.75

0.045

0.03

16–18

10–14

2–3

0.10

SS 317/317L

0.08/0.03

2.0

0.75

0.045

0.03

18–20

11–15

3–4

0.10

SS 321/321H

0.08/0.10

2.0

0.75

0.045

0.03

17–19

9–13

–

0.10

SS 347/347H

0.08/0.10

2.0

0.75

0.045

0.03

17–19

9–13

–

0.10

SS 904L

0.02

2.0

1.0

0.045

0.03

19–23

23–28

4–5

0.10

Physical Properties of Stainless Steel Forged Fittings

Property

SS 304/304L

SS 310/310S

SS 316/316L

SS 317/317L

SS 321/321H

SS 347/347H

SS 904L

Density (g/cm³)

8.0

7.9

8.0

8.0

8.0

7.9

8.0

Melting Point (°C)

1400–1450

1390–1450

1375–1400

1370–1400

1380–1420

1380–1420

1350–1390

Tensile Strength (MPa)

515–750

520–760

515–750

515–750

515–750

515–750

490–710

Yield Strength (MPa)

205–310

210–320

205–310

205–310

205–310

205–310

220–240

Elongation (%)

35–45

40

35–45

35–45

35–45

35–45

35

Hardness (HB)

150–200

150–200

150–200

150–200

150–200

150–200

170–190

Mechanical Properties Of Stainless Steel Forged Fittings

Grade

Tensile Strength (MPa)

Yield Strength (MPa)

Elongation (%)

SS 304/304L

515–750

205–310

35–45

SS 310/310S

520–760

210–320

40

SS 316/316L

515–750

205–310

35–45

SS 317/317L

515–750

205–310

35–45

SS 321/321H

515–750

205–310

35–45

SS 347/347H

515–750

205–310

35–45

SS 904L

490–710

220–240

35

Types Of Stainless Steel Forged Fittings We Offer

Stainless Steel Pipe Cap Fitting
Arrow
Stainless Steel Pipe Cross Fitting
Arrow
Stainless Steel Pipe Bend Fitting
Arrow
Stainless Steel Short Stub End Fitting
Arrow
Stainless Steel Long Stub End Fitting
Arrow
Stainless Steel Concentric Reducer Fitting
Arrow
Stainless Steel Eccentric Reducer Fitting
Arrow
Stainless Steel Tee Fitting
Arrow
Stainless Steel Elbow Fitting
Arrow

Materials We Offer

Alloy 20 Forged Fittings

Alloy 20

Nickel Forged Fittings

Nickel 200/201

Hastelloy Forged Fittings

Hastelloy c22/c276

Monel Forged Fittings

Monel 400/K500

Alloy Steel Forged Fittings

Alloy steel

Copper Nickel Forged Fittings

Copper Nickel 70/30
Copper Nickel 90/10

Inconel or Incoloy Forged Fittings

Inconel 600/601/625/718
Incoloy 800/800HT/825

Carbon Steel Forged Fittings

Carbon Steel Forged Fittings

Duplex or Super Duplex Forged Fittings

Duplex Steel 31803/32205
Super Duplex S32760/S32750

Titanium Forged Fittings

Titanium Gr 1
Titanium Gr 2
Titanium Gr 5
Titanium Gr 9

Stainless Steel Forged Fittings

SS 304/304L/304H
SS 347/347H
SS 309/310/310S
SS 347/347H
SS 316/316L/316Ti
SS 904L
SS 317/317L

FAQ

Your complete guide to understanding Steelvron’s products, materials, certifications, and industrial applications worldwide

Why choose Steelvron as your Stainless Steel Forged Fittings Supplier?
arrow

Steelvron delivers premium-quality forged fittings with corrosion resistance, strength, and adherence to global standards like ASTM, ASME, DIN, and EN.

Which grades of Stainless Steel Forged Fittings do you supply?
arrow

We supply SS 304/304L/304H, 309/310/310S, 316/316L/316Ti, 317/317L, 321/321H, 347/347H, and SS 904L.

What industries use Stainless Steel Forged Fittings?
arrow

They are widely used in oil & gas, petrochemicals, food processing, pharmaceuticals, marine, and power generation sectors.

What size range is available?
arrow

Our forged fittings are available from ½” (15 NB) to 4” (100 NB), with pressure ratings up to Class 9000.

Do you provide customized forged fittings?
arrow

Yes, Steelvron manufactures fittings as per client specifications, including custom dimensions, threading, and pressure classes.
