Alloy Steel Forged Fittings

Steelvron is a trusted Alloy Steel Forged Fittings Supplier, Manufacturer, and Exporter, offering high-strength, durable, and precision-engineered fittings designed for demanding industrial applications. Alloy steel forged fittings are renowned for their superior toughness, wear resistance, and ability to withstand extreme temperatures and pressures, making them ideal for oil & gas, petrochemical, chemical, and refining industries.

Overview

Manufactured from premium alloy steel grades, our fittings ensure high mechanical strength, impact resistance, and reliable performance in harsh operational environments. These fittings are specifically designed to endure high-pressure pipelines, thermal cycling, and corrosive conditions, offering long service life with minimal maintenance requirements.

Steelvron’s Alloy Steel Forged Fittings are produced using advanced forging techniques, ensuring dimensional accuracy, leak-proof connections, and uniform wall thickness. All products comply with ASTM, ASME, DIN, EN, and JIS standards, delivering safety, efficiency, and performance reliability for critical pipeline systems.

We supply a comprehensive range of alloy steel forged fittings, including elbows, tees, reducers, caps, crosses, couplings, and custom-designed components, tailored to meet project-specific requirements and complex piping configurations.

Technical Specifications of Alloy Steel Forged Fittings

Standards:

ASTM A105 / A182, ASME SA105 / SA182, MSS-SP-79, MSS-SP-83, ANSI, DIN, EN, JIS

Grades Available:

Alloy Steel (e.g., ASTM A182 F1–F91, ASTM A105, ASTM A350 LF2)

Forms:

Elbows, Tees, Crosses, Reducers, Couplings, Unions, Plugs, Bushings, Custom Forged Fittings

Size Range:

½” (15 NB) to 6” (150 NB)

Pressure Class:

2000, 3000, 6000, 9000 LBS

Finish:

Black Coated, Galvanized, CNC Machined, Heat-Treated

Chemical Properties Of Alloy Steel Forged Fittings

Grade	C (max)	Mn (max)	Si (max)	P (max)	S (max)	Cr (min)	Ni (min)	Mo (min)
ASTM A105	0.35	1.05	0.35	0.035	0.040	–	–	–
ASTM A182 F11	0.15	0.45	0.35	0.035	0.035	1.0	0.5	0.5
ASTM A182 F22	0.15	0.45	0.35	0.035	0.035	2.0	0.5	0.9

Physical Properties of Alloy Steel Forged Fittings

Property

ASTM A105

ASTM A182 F11

ASTM A182 F22

Density (g/cm³)

7.85

7.85

7.85

Tensile Strength (MPa)

485–655

485–620

485–655

Yield Strength (MPa)

250

240

250

Elongation (%)

22

22

20

Hardness (HB)

170–220

170–220

200–230

Operating Temp

Up to 450°C

Up to 540°C

Up to 580°C

Types Of Alloy Steel Forged Fittings We Offer

Alloy Steel Pipe Cap Fitting

Alloy Steel Pipe Cross Fitting

Alloy Steel Pipe Bend Fitting

Alloy Steel Short Stub End Fitting

Alloy Steel Long Stub End Fitting

Alloy Steel Concentric Reducer Fitting

Alloy Steel Eccentric Reducer Fitting

Alloy Steel Tee Fitting

Alloy Steel Elbow Fitting

Materials We Offer

Carbon Steel Forged Fittings

Duplex or Super Duplex Forged Fittings

Duplex Steel 31803/32205

Super Duplex S32760/S32750

Titanium Forged Fittings

Stainless Steel Forged Fittings

FAQ

Your complete guide to understanding Steelvron’s products, materials, certifications, and industrial applications worldwide

Why choose Steelvron as your Alloy Steel Forged Fittings Supplier?

Steelvron provides high-strength, durable alloy steel forged fittings that comply with ASTM, ASME, DIN, EN, and JIS standards, ensuring reliable performance in critical industrial operations.

Which grades of Alloy Steel Forged Fittings do you supply?

We supply ASTM A105, ASTM A182 F1–F91, and ASTM A350 LF2 grades.

What is the size and pressure class range available?

Sizes range from ½” (15 NB) to 6” (150 NB) with pressure ratings of 2000, 3000, 6000, and 9000 LBS.

Are Alloy Steel Forged Fittings suitable for high-temperature and high-pressure applications?

Yes, they are specifically designed for high-pressure, high-temperature, and corrosive environments in oil, gas, and chemical industries.

Why Choose Us?

Global Expertise

Trusted manufacturer, supplier, and exporter of Alloy Steel Forged Fittings worldwide.

Complete Range

Comprehensive portfolio covering all Alloy Steel Forged Fittings materials and types, ensuring broad compatibility.

Certified Quality

ISO-certified facilities ensure strict manufacturing and testing, delivering precision products consistently.

International Standards

Products meet ASME, ANSI, DIN, EN, BS, and JIS norms, ensuring acceptance.

Custom Solutions

Supplying standard and tailor-made Alloy Steel Forged Fittings, crafted to match exact specifications.

Worldwide Reach

Exporting to 50+ countries with a proven record of client satisfaction.

Property	ASTM A105	ASTM A182 F11	ASTM A182 F22
Density (g/cm³)	7.85	7.85	7.85
Tensile Strength (MPa)	485–655	485–620	485–655
Yield Strength (MPa)	250	240	250
Elongation (%)	22	22	20
Hardness (HB)	170–220	170–220	200–230
Operating Temp	Up to 450°C	Up to 540°C	Up to 580°C
